Not all hazardous pipes are equal.

A pipe carrying sulfuric acid and a pipe carrying natural gas are both dangerous — but they're dangerous in completely different ways. ASME A13.1 handles this by dividing hazardous pipe systems into two separate color categories based on how dangerous the contents are.

Understanding when to use yellow/black versus orange/black is one of the most important decisions in any hazardous pipe marking project.

This guide breaks down both categories, gives real-world examples of each, and covers the label text and placement rules you need.

---

The Two Hazardous Material Colors in ASME A13.1

ASME A13.1 divides hazardous pipe contents into two levels of danger:

---

Hazardous Materials → Yellow / Black

Yellow background with black text is used for materials that are flammable, combustible, chemically active, or otherwise hazardous — but where the hazard level doesn't rise to the "immediately dangerous" threshold.

Think of yellow/black as: dangerous, handle with caution.

Yellow/Black applies to:

• Combustible liquids (flash point above 100°F)
• Acids and corrosives at moderate concentrations
• Alkalis and caustics
• Mildly toxic substances
• Oxidizers (non-extreme)
• Steam condensate classified as hazardous
• Hot oil systems
• High-temperature water above safe handling thresholds

---

Toxic / Extra Hazardous → Orange / Black

Orange background with black text is used for materials that are immediately dangerous to life and health (IDLH) — highly toxic, highly corrosive, highly flammable at any concentration, or presenting an extreme hazard even in small quantities.

Think of orange/black as: extreme hazard, immediate danger.

Orange/Black applies to:

• Highly toxic chemicals (acids at high concentration, chlorine, phosgene, hydrogen sulfide)
• Highly flammable gases (hydrogen, acetylene, propane at high pressure)
• Oxidizers — extreme (fuming nitric acid, perchloric acid)
• Refrigerants (see refrigerant pipe marking article)
• Anhydrous ammonia
• Highly corrosive substances (hydrofluoric acid, concentrated sulfuric acid)

---

When to Use Each — Real World Examples

Here's how some common industrial pipe contents map to the two colors:

If you're uncertain which category a specific chemical falls into, consult the Safety Data Sheet (SDS) for the substance and look for the IDLH (Immediately Dangerous to Life and Health) value. If the substance has a low IDLH value or is classified as highly toxic, highly flammable, or highly corrosive — use orange/black.

---

Standard Label Text for Hazardous Pipe Systems

The label text on a hazardous pipe marker must clearly identify the pipe contents. Vague labels like "ACID" or "CHEMICAL" are not adequate when lives and safety depend on workers knowing exactly what they're dealing with.

For exceptionally dangerous chemicals — HF, chlorine, high-concentration sulfuric acid — many facilities add a secondary warning text below the chemical name. "EXTREME HAZARD" or "IMMEDIATELY DANGEROUS" below the chemical name reinforces the severity.

---

The Role of OSHA Hazard Communication (HazCom)

OSHA's Hazard Communication Standard (29 CFR 1910.1200 — "HazCom") requires that workers be informed about the hazardous chemicals they work with. This includes:

• Safety Data Sheets (SDS) for every hazardous chemical
• Labels on containers
• Employee training

Pipe markers on chemical piping systems support HazCom compliance. They're not a substitute for container labels or SDS — but a worker who can see a labeled pipe knows immediately that they're working near a hazardous substance.

OSHA's Process Safety Management standard (29 CFR 1910.119) also requires identification of piping systems in processes involving highly hazardous chemicals. Proper pipe markers are a fundamental part of any PSM-covered facility's safety program.

---

GHS Pictograms and Pipe Markers

The Globally Harmonized System of Classification and Labelling of Chemicals (GHS) introduced standardized pictograms for chemical hazards — flame, skull and crossbones, corrosion symbol, exclamation mark, and others.

Some facilities add GHS-compatible hazard pictograms to their pipe markers on chemical lines. This is above and beyond ASME A13.1 requirements but adds an immediate visual warning that doesn't require reading the text.

Common pictograms used on chemical pipe markers:

• Skull/crossbones (toxic) on chlorine, HF, concentrated acid lines
• Flame (flammable) on hydrogen, acetylene, solvent lines
• Corrosion symbol on acid and caustic lines
• Exclamation mark (irritant/health hazard) on moderate-hazard chemical lines

Custom pipe markers with integrated GHS pictograms are available from Print Pro AZ for applications where the additional visual warning is needed.

---

Pipe Marker Sizing for Chemical Lines

Chemical process piping varies enormously in size — from small ½" laboratory chemical lines up to large 12"+ process headers in industrial plants.

Use the standard ASME A13.1 size chart:

For laboratory chemical distribution systems (typically ½" to 1" tubing), the 8" × 1⅛" label is standard. Industrial process chemical headers (2" to 8") use the 14" or 24" label. Large process plant headers may need the 32" label.

---

Placement Rules for Hazardous Chemical Piping

All ASME A13.1 placement rules apply — and for hazardous chemical piping, err toward more labels rather than fewer:

At every process connection — Any place where a worker might interact with the pipe — sampling points, connections to reactors, injection points, heat exchangers — needs a label.

At every valve, including isolation and control valves — Chemical systems have many valves. Label both sides of every valve, including automated control valves, throttling valves, and check valves.

At every branch — Chemical distribution systems often feed multiple process points. Label every branch at the takeoff.

At every penetration — Both sides of every wall, floor, and ceiling penetration. Chemical lines that pass between process areas need labels visible from both sides.

At the storage tank / source connection — Label the outlet of every chemical storage tank and every connection where chemical is transferred into the distribution system.

At the point of use — Label at every piece of equipment that consumes the chemical: reactors, heat exchangers, scrubbers, injection pumps, neutralization systems.

Every 20–25 feet on straight runs — For highly hazardous chemical lines (orange/black), consider 20–25 foot intervals rather than the standard 25–50 feet.

---

Special Situations: Chemical Compatibility with Label Materials

Standard vinyl pipe markers work on most chemical pipe systems. But some chemicals attack vinyl — especially:

• Hydrofluoric acid (HF)
• Concentrated sulfuric acid
• Concentrated nitric acid
• Strong oxidizers
• Some ketones and solvents

For these applications, ask about chemical-resistant label materials when ordering. Using the wrong label material on an aggressive chemical line can result in labels that dissolve, peel, or fail — leaving a hazardous pipe unlabeled.

Print Pro AZ can advise on the right label material for your specific chemical application.

---

Conducting a Hazardous Pipe Marking Audit

If you're responsible for a facility with chemical piping and aren't sure your labeling is complete, a pipe marking audit is the right first step:

1. Walk every chemical pipe run from source to point of use.
2. Document what's in each pipe — verify against SDS and P&IDs.
3. Identify unlabeled or mislabeled segments.
4. Check label condition — faded, peeling, or chemically attacked labels count as unlabeled.
5. Verify color accuracy — yellow/black vs. orange/black based on hazard level.
6. Check placement — valves, branches, penetrations, intervals.
7. Order and install missing labels — then re-walk to verify.

For complex chemical facilities, a formal pipe marking audit with documentation is a valuable tool for OSHA compliance, PSM programs, and insurance purposes.

---

Shop Hazardous Chemical Pipe Markers

Print Pro AZ stocks yellow/black and orange/black chemical pipe markers in all standard ASME A13.1 sizes — with custom text options for any chemical. Same-day shipping. Made in the USA.

👉 Shop Yellow/Black Pipe Markers (Hazardous) → 👉 Shop Orange/Black Pipe Markers (Extra Hazardous) → 👉 Need custom chemical names or GHS pictograms? Order Custom Markers →

---

Frequently Asked Questions

What color are hazardous chemical pipe markers? ASME A13.1 uses two colors for hazardous pipe systems: yellow/black for hazardous materials (flammable, corrosive, chemically active) and orange/black for extra-hazardous materials that are immediately dangerous to life and health.

What is the difference between yellow/black and orange/black pipe markers? Yellow/black indicates a hazardous material — dangerous but not immediately life-threatening in normal conditions. Orange/black indicates an extra-hazardous material — immediately dangerous to life and health, highly toxic, or highly flammable. When in doubt, use the Safety Data Sheet IDLH value to determine the correct classification.

What color is sulfuric acid pipe marking? Dilute sulfuric acid typically uses yellow/black. Concentrated sulfuric acid (fuming, oleum) typically uses orange/black due to the extreme corrosion risk and IDLH classification. Check the SDS for your specific concentration.

Does OSHA require hazardous chemical pipe marking? OSHA's HazCom standard (1910.1200) and Process Safety Management standard (1910.119) both support the need for pipe identification in facilities with hazardous chemicals. ASME A13.1 is the accepted standard for this identification. The General Duty Clause can be used to cite employers for unmarked hazardous chemical piping.

What label text should I use on an acid line? Use the specific chemical name — "SULFURIC ACID," "HYDROCHLORIC ACID," "HYDROFLUORIC ACID" — rather than a generic "ACID" label. Workers and emergency responders need to know exactly what chemical they're dealing with.

Can I add hazard symbols to pipe markers? Yes. GHS-compatible hazard pictograms (flame, skull, corrosion) can be added to custom pipe markers for additional visual warning on high-hazard chemical lines. Print Pro AZ offers custom markers with integrated pictograms.

What label material should I use on chemical lines? Standard vinyl works for most applications. For aggressive chemicals like HF, concentrated acids, strong oxidizers, or solvents, use chemical-resistant label materials. Contact Print Pro AZ to identify the right material for your specific chemical.
